● Electric ratings: AC50/6OHz,690v,up to 95A;
● Utilization category: AC-3,AC-4;
● Altitude: ≤ 2000m;
● Ambient temperature: -5°C~+40°C;
● Mounting category: III;
● Mounting condlitions: Inclination between the mounting planeand the verticall plane should not
exceed ±5°;
● Standard: IEG/EN 60947-4=IEC/EN 60947-5-1.
● Gontrol Goil valtage(AC Goil Operation).
Application scenarios:
Usually installed in the distribution box on the floor, computer center,telecommunication room,elevator control room,cable TV room,building control room, fire center, industrial automatic control area, hospital operation room,monitoring room and distribution box equipment with electronic medical device.
| Midel | 2 Cabling cross Section(cu) | Screw size | Tighteningtorque(N. m) | |||
| Numbet of piece | Flexible cable with cold-prossed socKet(mm2) | Flexible cable without cold-pressed socket(mm2) | lnflekible cable(mm2) | |||
| JLC1-09 | 1-2 | 2.5 | 4 | 4 | M3.5 | 0.8 |
| JLC1-12 | 1-2 | 2.5 | 4 | 4 | M3.5 | 0.8 |
| JLC1-18 | 1-2 | 4 | 6 | 6 | M3.5 | 0.8 |
| JLC1-25 | 1 | 4 | 10 | 6 | M4 | 1.2 |
| 2 | 4 | 6 | 6 | M4 | 1.2 | |
| JLC1-32 | 1 | 4 | 10 | 6 | M4 | 1.2 |
| 2 | 4 | 6 | 6 | M4 | 1.2 | |
| JLC1-40 | 1 | 10 | 16 | 10 | M4 | 3.5 |
| 2 | 10 | 10 | 10 | M8 | 3.5 | |
| JLC1-50 | 1 | 16 | 25 | 25 | M8 | 3.5 |
| 2 | 16 | 16 | - | M8 | 3.5 | |
| JLC1-65 | 1 | 16 | 25 | 25 | M8 | 3.5 |
| 2 | 16 | 16 | - | M8 | 3.5 | |
| JLC1-80 | 1 | 50 | 50 | 50 | M8 | 3.5 |
| 2 | 25 | 35 | - | M10 | 4.0 | |
| JLC1-95 | 1 | 50 | 20 | 50 | M10 | 4.0 |
| 2 | 25 | 35 | - | M10 | 4.0 | |
