Home / Product / Contactors / AC Contactors
Siemens products are environment friendly, which predominantly consist of recyclable material for disposal we recommend disassembling and separation into following materials
Metal:Segregate into ferrous & non ferrous types for recycling through author land dealer
Plastic: Segregate as per material type for recycling through author land dealer because of the long life time of Siemens products the disposal guidelines may be replaced by other national regulations when taking the products out of service. The local customer care service is available at any time to answer disposal-related questions
| Voltage(V) | 24 | 42 | 48 | 110 | 230 | 380 | 415 | others |
| Code | B0 | D0 | H0 | F0 | P0 | Q0 | R0 | On enquiry |
Mounting dimensions (mm)
Permissible cross-sections for main auxiliary conductors solid
Finely stranded with end sleeve ： 2×0.5 to 1mm
AWG wires：2 x 1 to 2.5mm
Tightening torque standard type:
1x 4mm
2x 0.75 to 2.5mm
2x AWG 18-12
0.8 to 1.4Nm/7 to 12 Lb-in
Tightening torque auxiliary contact block 0.8 to 1.1Nm/7 to 12Lb-in
Remove dust by section, discolored and rough contacts are still service worthy and should not be filed or greased
Replacement of the contacts is not recommended
Auxiliary contact block replacement(Common for AC contactor and DC contactor)
We take pride in our customer service and aim to provide 5-star support. If you have any questions about our products, feel free to call or email us.
The company mainly produces AC contactors, motor protectors and thermal relays.All products have passed the CE safety certification, and some have passed the CB certification.
