Six advantages:
1.Beautiful atmosphere
2.Small size and high segment
3.Double wire disconnect
4.Excellent cooper wire
5.Overload protection
6.Green product and environment protection
Shipping way
Aproducts can be deliveyr by sea, by air, by express carrier,etc.
| Midel | 2 Cabling cross Section(cu) | Screw size | Tighteningtorque(N. m) | |||
| Numbet of piece | Flexible cable with cold-prossed socKet(mm2) | Flexible cable without cold-pressed socket(mm2) | lnflekible cable(mm2) | |||
| JLC1-09 | 1-2 | 2.5 | 4 | 4 | M3.5 | 0.8 |
| JLC1-12 | 1-2 | 2.5 | 4 | 4 | M3.5 | 0.8 |
| JLC1-18 | 1-2 | 4 | 6 | 6 | M3.5 | 0.8 |
| JLC1-25 | 1 | 4 | 10 | 6 | M4 | 1.2 |
| 2 | 4 | 6 | 6 | M4 | 1.2 | |
| JLC1-32 | 1 | 4 | 10 | 6 | M4 | 1.2 |
| 2 | 4 | 6 | 6 | M4 | 1.2 | |
| JLC1-40 | 1 | 10 | 16 | 10 | M4 | 3.5 |
| 2 | 10 | 10 | 10 | M8 | 3.5 | |
| JLC1-50 | 1 | 16 | 25 | 25 | M8 | 3.5 |
| 2 | 16 | 16 | - | M8 | 3.5 | |
| JLC1-65 | 1 | 16 | 25 | 25 | M8 | 3.5 |
| 2 | 16 | 16 | - | M8 | 3.5 | |
| JLC1-80 | 1 | 50 | 50 | 50 | M8 | 3.5 |
| 2 | 25 | 35 | - | M10 | 4.0 | |
| JLC1-95 | 1 | 50 | 20 | 50 | M10 | 4.0 |
| 2 | 25 | 35 | - | M10 | 4.0 | |
We take pride in our customer service and aim to provide 5-star support. If you have any questions about our products, feel free to call or email us.
The company mainly produces AC contactors, motor protectors and thermal relays.All products have passed the CE safety certification, and some have passed the CB certification.
