Home / Product / Contactors / AC Contactors
Application: Remote making & breaking circuits; protect circuit from over-load when assembling
with thermal over-load relay;frequent start-up and control of AC contactor;
Shipping way
By sea, by air, by express carrier
| Midel | 2 Cabling cross Section(cu) | Screw size | Tighteningtorque(N. m) | |||
| Numbet of piece | Flexible cable with cold-prossed socKet(mm2) | Flexible cable without cold-pressed socket(mm2) | lnflekible cable(mm2) | |||
| JLC1-09 | 1-2 | 2.5 | 4 | 4 | M3.5 | 0.8 |
| JLC1-12 | 1-2 | 2.5 | 4 | 4 | M3.5 | 0.8 |
| JLC1-18 | 1-2 | 4 | 6 | 6 | M3.5 | 0.8 |
| JLC1-25 | 1 | 4 | 10 | 6 | M4 | 1.2 |
| 2 | 4 | 6 | 6 | M4 | 1.2 | |
| JLC1-32 | 1 | 4 | 10 | 6 | M4 | 1.2 |
| 2 | 4 | 6 | 6 | M4 | 1.2 | |
| JLC1-40 | 1 | 10 | 16 | 10 | M4 | 3.5 |
| 2 | 10 | 10 | 10 | M8 | 3.5 | |
| JLC1-50 | 1 | 16 | 25 | 25 | M8 | 3.5 |
| 2 | 16 | 16 | - | M8 | 3.5 | |
| JLC1-65 | 1 | 16 | 25 | 25 | M8 | 3.5 |
| 2 | 16 | 16 | - | M8 | 3.5 | |
| JLC1-80 | 1 | 50 | 50 | 50 | M8 | 3.5 |
| 2 | 25 | 35 | - | M10 | 4.0 | |
| JLC1-95 | 1 | 50 | 20 | 50 | M10 | 4.0 |
| 2 | 25 | 35 | - | M10 | 4.0 | |
